Ui24R User Manual
5.6: PATCHING
5.6 PATCHING
SOUNDCHECK ASSIGN PAGE
The Soundcheck Assign page assigns the soundcheck patch for the selected channel.
SOUNDCHECK INDICATOR
The Soundcheck Indicator is located in the top left corner of the Level 1 LCD Panel. This will
appear to indicate when the Ui is in Soundcheck Mode.
