SoundCraft Ui24R User Manual

Ui24R User Manual
9.0.1: MTK PLAYER & RECORDER
MTK PLAYBACK & RECORDING
9.0.1: MTK PLAYBACK & RECORDING
MULTI-TRACK PLAYBACK & RECORDING FROM USB
The Ui24R can playback and record multi-track from USB up to 22 tracks. Patches will be set by dou-
ble clicking a mixer patch slot which will open up the mixer patch assignment modal. Any changes will
be universal. Sessions, Mixer Patches and Files are all displayed on this screen.
By clicking on a session number, playback will commence once the play icon is activated and
stopped with the stop button, Recording will commence or stop by activating the record button.

SoundCraft Ui24R Specifications

General

Channels quantity	24 channels
Digital sound processing	- bit
Microphone in	Yes
Master (XLR) out	8
Line inputs (RCA)	1
Headphone connectivity	6.3 mm
Number of microphone inputs	10
Rack capacity	4U
Video capability	-
USB connector type	USB Type-A, USB Type-B
LED indicators	Wi-Fi
Built-in display	No

Weight and Dimensions

Package weight	13600 g
