2-7
Description of stud welder
R
2.4 Technical data
Designation
Welding range
Welding process
Standard pistol
Current source
Charging capacity
Charging voltage
Welding time
Welding sequence
Power supply
Fuse element at
front panel
Welding cable
Earth cable
Weight *
Colour
Subject to technical changes
BMS-10N
M3 - M8 or Ø 2 - 8 mm with
steel and stainless steel,
M3 - M8 or Ø 2 - 8 mm
with aluminium and brass,
depending on requirements
Tip ignition as per DVS Leaflet 0903 with gap and
contact welding
Stud welding pistol PS-3
Capacitor battery
88,000 µF
50 - 200 V infinitely variable up/down
0.001 - 0.003 sec.
up to 20 studs/min, depending on stud diameter
220/230 V, 50/60 Hz, 10 AT, +/- 10 %
(special voltage on request)
0.1 AT for main switch
10 AT for control transformer
3 m highly flexible
2 x 3 m highly flexible
19.5 kg
RAL 5009 azure
SZ.0042.E
BMS-10NV
Like stud welder BMS-10N
but steel studs up to M10
132,000 µF
20.5 kg
*Slight deviations are possible depending on accessories (e.g. automatic set)
