13-44
Spare parts
R
13.7 Spare parts list for BMS-10N stud welder - View D and E
Item No. Quantity Description Order No.
1 1 Back panel F03599
2 1 Complete pulse counter F03708/FA
3 1 STA-41 PCB mounting plate F03600
4 2 Spring ring M4 M01074
5 2 Hexagon nut M4 M01012
6 2 Grommet E03619
7 3 Coupler socket KD-1/8 M01299
8 1 Coupler plug KS-1/4 M01302
9 2 Flat-head screw M3x16 M01349
10 1 Mounting plate F02992
11 2 Sound absorber U-M5 M01284
12 1 Angular joining piece M5/PU-4 M02068
13 0.25m Pneumatic hose PU-4 M01306
14 1 Connection board M02101
15 1 Pneumatic valve M02099
16 2 Tooth lock washer M3 M01318
17 2 Hexagon nut M3 M01011
18 2 Angular joining piece M5/PU-3 M01056
19 2m Pneumatic hose SMC4 M01067
20 1 Joining piece QM-1/4 M01290
21 1 Sound absorber U-1/8 M01285
22 1 Reducer M01538
23 1 Elbow PU-4 M03518
24 1 Pneumatic valve M02098
25 1 Pin-and-socket connector, straight KQH-06M02095
26 4 Washer M4 M01062
27 4 Spring ring M4 M01074
28 4 Hexagon nut M4 M01012
29 2 Joining piece QM-1/8 M01289
30 2 Pin-and-socket connector, straight M01060
31 2 Angular joining piece 1/8-PU-3 M01058
32 2 Hexagon nut M4 M01012
33 2 Spring ring M4 M01074
34 1 Mains filter E03541
35 3 Binder with flange E02651
36 2 Spacing bolt M3x18 M01705
37 1 Covering plate E02659
