13-42
Spare parts
R
13.5 Spare parts list for BMS-10N stud welder - View B and C
Item No. Quantity Description Order No.
1 4 Cheese-head screw M4x16 M01089
2 1 Protective grating E02224
3 3 Fan 220/230 volt E02083
4 1 Covering plate for fan F03789
5 4 Hexagon nut M4 M01012
6 4 Spring ring M4 M01074
7 4 Spring ring M4 M01074
8 4 Hexagon nut M4 M01012
9 4 Flat-head screw M4x16 M01354
10 2 Cheese-head screw M4x12 M01152
11 2 Spring ring M6 M01076
12 2 Hexagon nut M6 M01014
13 1 Fan elbow F01298
14 1 Fan 24V TYPE 4715KL E03514
15 2 Hexagon nut M4 M01012
16 2 Spring ring M4 M01074
17 8 Spring ring M5 M01075
18 8 Hexagon head cap screw M5x12 M01117
19 4 Hexagon nut M4 M01012
20 4 Spring ring M4 M01074
20.1 4 Nylon washer E03728
20.2 4 Insulating disk E02037
21 1 Busbar, left F01299
22 1 Busbar, middle F01301
23 1 Busbar, right F01300
24 3 Hexagon nut M8 M01015
25 3 Spring ring M8 M01077
26 3 Washer M8 M01065
27 1 Connecting cable F03627/FA-E
28 1 Connecting cable F03628/FA-E
29 3 Hexagon head cap screw M8x16 M01129
30 4 Aluminium capacitor 22000µF E01199
31 1 Connecting cable F03627/FA-E
32 1 Connecting cable F03628/FA-E
33 4 Insulating plastic tube 175mm M01246
34 4 Threaded rod M4x185mm M03516
35 4 PVC hose, black M01310
36 4 Hexagon nut M4 M01012
