13-40
Spare parts
R
13.3 Spare parts list for BMS-10N stud welder - View A
Item No. Quantity Description Order No.
1 2 Threaded rod M4x140mm M01242
2 2 Spring ring M4 M01074
3 2 Hexagon nut M4 M01012
4 2 Spacing bolt M4x10 M01047
5 2 Resistor covering plate F03601
6 2 Flat-head screw M4x8 M01351
7 4 Distance sleeve Ø7x15 M01262
8 16 Distance sleeve Ø7x10 M01261
9 3 Wire resistor 7.5R/100W E02089
10 5 Wire resistor 15R/100W E01986
11 16 Resistor mounting plate F01296
12 2 Hexagon nut M4 M01012
13 1 Cheese-head screw M5x50 M01178
14 1 Spring ring M5 M01075
15 1 Washer M5 M01063
16 1 Washer, special size M6 M01707
17 1 Toroidal mains transformer BV 47718 E03537
18 4 Hexagon nut M4 M01012
19 4 Spring ring M4 M01074
20 1 Connecting cable for pulse counter F03707/FA-E
21 1 Complete flat cable, 26-pole F03617/FA-E
22 1 Fine-wire fuse 10AT E01898
23 1 Fine-wire fuse 1.6AT E03608
24 1 Fine-wire fuse 3.15 AT E01895
25 1 PC Board STA-41 F03630/FA
26 2 Hexagon nut M4 M01012
27 1 Complete flat cable F03636/FA-E
28 2 Spacing bolt M4 x 15 M01031
29 4 Hexagon nut M4 M01012
30 4 Spring ring M4 M 1074
31 1 Transformer mounting plate F03750
32 1 Insulating disk for transformer E02222
33 4 Hexagon nut M4 M01012
34 2 Threaded rod M4x140mm M01242
35 4 Insulating plastic tube 65mm M01246
36 4 PVC hose, black M01310
37 4 Hexagon nut M4 M01012
38 1 Lower part of housing F03596
39 2 Threaded rod M4x85mm M01244
