Soyer BMS-10N - Spare Parts List for BMS-10 N Stud Welder - View F

13-46
Spare parts
R
13.9 Spare parts list for BMS-10N stud welder - View F
Item No. Quantity Description Order No.
1 4 Hexagon nut M4 M01012
2 4 Spring ring M4 M01074
3 1 PC Board STA-31 F03616/FA
4 4 Distance sleeve 7x1.4x10mm M01261
5 4 Distance sleeve 7x1.4x7mm M01260
8 1 Mounting plate E01524
9 1 Fastening set M03576
10 1 Complete flat cable (see item 27/A) F03636/FA-E
11 1 Toroidal core E03607
12 1 Mounting base, self-adhesive E01726
13 4 Hexagon nut M4 M01012
14 4 Spring ring M4 M01074
15 4 Washer M4 M01062
16 1 Front panel with foil F03614/FA
17 1 Mounting base, self-adhesive E01726
18 1 Main switch E03512
19 4 Flat-head screw M4x16 M01354
20 1 Complete turning knob comprising:
1 Turning knob E01900
1 Nut cover E01902
1 Front cap E01904
21 2 Earth connector E01964
22 1 Earth socket E01958
23 2 Pin-and-socket connector, straight M01060
24 1 Fine-wire fuse 0.1AT E03504
25 1 Fine-wire fuse 10AT E01898
26 2 Locking screw E01891
27 2 Coupler socket KD-1/8 M01299
28 1 Copper plate F03529
29 2 Hexagon nut M8 M01015
30 2 Spring ring M8 M01077
31 2 Washer M8 M01065
32 1 Connecting cable F03628/FA-E
33 2 Thyristor clamping cap E01987
34 1 Thyristor SAE4A (not illustrated) E01361
34.1 1 Diode 470 POA40 (not illustrated) E01817
35 2 Hexagon head cap screw M8x16 M01129
36 1 Mains cable E01985
37 8 Washer M5 M01063
38 8 Spring ring M5 M01075
39 8 Hexagon nut M5 M01013
40 1 Hardboard F03527
41 1 Cable gland PG11 E01969
42 1 Lock nut PG11 E01970
43 1 Connecting cable F03619/FA-E
44 1 Crimp lug 8 x 6 mm
2
E02046
