Appendix A/PS-3 - Initiation - Capacitor Discharge
2.2 Connecting stud welding pistols to stud welder
The stud welding pistols are connected to the stud welder by means of pistol
and control cables.
2.3 Operation
• Connect stud welder to earth
• Connect stud welding pistol as described in chapter 5
• Adjust stud welding pistol as described in Appendix A, Chapter 1
• Connect stud welder to the mains supply
• Adjust stud welder for the welding studs to be used
• Insert welding studs into stud holder
• Place stud welding pistol upon workpiece and press trigger switch
