Soyer BMS-10N - Fuse

5-21
R
Initiation
• Air function "forward" (item 8, chapter 5.1, optional)
Connection for welding pistols or heads with automatic stud feed.
• Air function "backward" (item 9, chapter 5.1, optional)
Connection for welding pistols or heads with automatic stud feed.
5.2.4 Fuse
• Fuse (item 1 and 3, chapter 5.1)
The stud welder is protected by two fuses:
0.1 AT and 10 AT.
WARNING
If you have to replace fuses, only use those with specified electrical values.
Oversized fuses could either cause defects to the electrical system or a fire.
Ꮨ
Disconnect the mains plug from the power supply when replacing fuses!
