SPECS HSA3500 User Manual

HSA config files (*.hsa)
{
MinValue = -0.0
MaxValue = +3500.0
}
[LogicalVoltage] "Pass Energy"
{
MinValue = -0.0
MaxValue = +660.0
}
[LogicalVoltage] "Focus Displacement 1"
{
MinValue = -1
MaxValue = +1
}
[LogicalVoltage] "Focus Displacement 2"
{
MinValue = -1
MaxValue = +1
}
[DacVoltage] CoilCurrent
{
DacId = 16.0
OperationMode = 0
Formula = $Icoil * 0.001 # User Interface Unit = mA
}
[DacVoltage] NonLinearLens1
{
DacId = 1.0
OperationMode = 3
Formula = -$Ekin+$WF+ $Ep * spline_LargeArea_T2(-(-$Ekin + $WF) / $Ep)
}
[DacVoltage] NonLinearLens2
{
DacId = 3.0
OperationMode = 3
Formula = -$Ekin+$WF+ $Ep * spline_LargeArea_T3(-(-$Ekin + $WF) / $Ep)
}
[DacVoltage] Lens3
{
DacId = 5.0
OperationMode = 3
Formula = -$Ekin+$WF+ $Ep * spline_LargeArea_T4_T7(-(-$Ekin + $WF) / $Ep)
}
[DacVoltage] Lens4
{
42 HSA3500 / HSA3500 plus Power Supply
