DacId = 7.0
OperationMode = 3
Formula = -$Ekin+$WF+ $Ep * spline_LargeArea_T8(-(-$Ekin + $WF) / $Ep)
}
[DacVoltage] Lens5
{
DacId = 6.0
OperationMode = 3
Formula = -$Ekin+$WF+ $Ep * spline_LargeArea_T9(-(-$Ekin + $WF) / $Ep)
}
[DacVoltage] EkBase
{
DacId = 9.0
MaxStep = 45.0
OperationMode = 3
Formula = -(&Offset[0] + &Gain[0] * $Ekin) + $Ep + $WF # + Ekin +
Epass by hardware
}
[DacVoltage] OuterHemisphere = AnalyzerVoltages/MacroOuterHemisphere
[DacVoltage] GroundPlate = AnalyzerVoltages/MacroGroundPlate
[DacVoltage] InnerHemisphere = AnalyzerVoltages/MacroInnerHemisphere
[DacVoltage] OuterHemispherePlate = AnalyzerVoltages/MacroOuterHemisphere-
Plate
[DacVoltage] InnerHemispherePlate = AnalyzerVoltages/MacroInnerHemisphere-
Plate
[DacVoltage] ConversionVoltage
{
DacId = 0.0
MaxStep = 45.0
OperationMode = 3
Formula = -$Ekin + $Uconv + $Ep + $WF
}
[DacVoltage] DetectorVoltage
{
DacId = 2.0
MaxStep = 45.0
OperationMode = 3
Formula = $Udet
}
[DacVoltage] ScreenVoltage
{
DacId = 4.0
MaxStep = 0.0
OperationMode = 3
HSA3500 / HSA3500 plus Power Supply 43
