#Slot 5: Type=0xf1 State=0x0020 Error=0x00
#Slot 6: Type=0xf1 State=0x0020 Error=0x00
#Slot 7: Nothing detected
#Slot 8: Type=0xf1 State=0x0020 Error=0x00
#Slot 9: Nothing detected
#Slot 10: Type=0xe1 State=0x0020 Error=0x00
#Slot 11: Nothing detected
#Slot 12: Nothing detected
#Slot 13: Nothing detected
#Slot 14: Nothing detected
#Slot 15: Nothing detected
#>
#>errors
#General=0 Cmd=0x00 ErrCode=0x00 FatalErr=0x00,0x00
#Total Error Counter: 0
#Fatal Error Code: 0x00
#Setup Error Code: 0x00
#EventCounter[0] = 0
#EventCounter[1] = 0
#EventCounter[2] = 0
#EventCounter[3] = 0
#EventCounter[4] = 0
#EventCounter[5] = 0
#EventCounter[6] = 0
#>
The example below shows the output for the following actions:
● Setting a mode
● the High Voltage is turned on
● the Voltage Monitor of the Analog-to-Digital Converter of Module 4 is read out
● the DAC of Module 4 is set to -50000 then 10000, each time reading the value at
the ADC
