Close the printer door until an audible ‘click’ is heard.
Discard any packing material from the paper roll. Place the roll in
the compartment as shown in the diagram. The paper must feed
from underneath the roll. The correct orientation of the paper is
critical (if you experience blank receipts, the paper may be
incorrectly inserted or of the wrong specification). Pull a length
of paper until it protrudes from the top of the terminal.
22
The SPw60, SPw70 and SPc50 terminals are all supplied with a paper roll. It may be loose in the box
or can be found in the terminal’s paper compartment. It is critical that only approved paper rolls are
used and these can be obtained from authorised paper roll supplier.
SPp60 And SPp70 Paper Roll Loading Procedure
Step 1
Step 3
Step 2
Place the terminal face down on the counter and gently pull
upwards on the lever located in the middle of the printer door.
Step 4
Turn the terminal over and tear off the excess.
Loading A Paper Roll
Page 22.
