122997-341 Operator Manual Safety Precautions
The tables below contain symbols which may be on your Basil 4600 Cage and Rack Washer or 4602 Cage and
Rack Washer components:
Table 1-1. Definition of Symbols on Unit
Symbol Definition
Protective Earth (Ground).
Warning! Risk of Electrical Shock.
Attention! Refer to Manual for Further Instructions.
Fuse Identification.
Pump Rotation
Table 1-2. Definition of Symbols on Identification Nameplate
Symbol Definition
MODEL Model Number of the Unit.
S/N Serial Number of the Unit.
V 3
~ Volt, Number of the Phase (Three) Alternating Current.
WIRE Number of Wires of the Unit, Ground not Included.
YEAR Year of Manufacture of the Unit.
kW Power Rating of the Unit
A Amperage.
Hz Hertz – Frequency of the Unit.
