4-24
122997-341 Operator Manual Washer Operation
4.10.1 Accessing Manual
Control Mode
To access Manual Control mode:
1. From Cycle Menu, press MANUAL MENU touch pad. Display
shows:
CYCLE 1 CYCLE 2
CYCLE 3 CYCLE 4
__indicates flashing position.
2. Display momentarily shows:
MANUAL CONTROL MENU
After four seconds, display shows Manual Control menu:
FILL
DRAIN
PUMP/DRV DRIVE
__indicates flashing position.
3. To perform specific manual functions, refer to descriptions
included in this section, titled same as shown on display screen.
FILL selection allows manual filling of chamber sump. DRAIN
selection allows manual draining of chamber sump and tanks.
PUMP/DRV selection allows manual operation of recirculation
pump(s) and oscillating jet system. DRIVE selection allows man-
ual operation of carriage drive system while chamber door is
open or closed.
4.10.2 FILL Function To access Manual FILL function:
1. In Manual Control Menu, press SELECT CYCLE touch pad until
FILL is flashing and press CYCLE/START touch pad. Display
shows:
FILLING SUMP...
PRESS STOP TO ABORT
NOTE: If necessary, manual functions can be aborted at any time
by pressing STOP/RESET touch pad.
2. When sump is full, display shows:
SUMP FULL
After a two second delay, display returns to Manual Control
Menu:
FILL DRAIN
PUMP/DRV DRIVE
__indicates flashing position.
