Steris Basil 4600 - Review and Print Specific Cycle Program

4-17
Washer Operation Operator Manual 122997-341
4.4 Review and Print
Specific Cycle Program
All cycle programs may be reviewed by accessing Cycle Review
mode when a cycle is not in progress. Cycle Review mode allows
user to review and printout cycle phases and values programmed for
specific cycle selected.
1. Press CYCLE MENU touch pad until desired cycle menu
appears on screen:
CYCLE 5
CYCLE 6
CYCLE 7 CYCLE 8
__indicates flashing position.
2. Press SELECT CYCLE touch pad until desired cycle name
flashes:
CYCLE 5 CYCLE 6
CYCLE 7 CYCLE 8
__indicates flashing position.
3. Press REVIEW CYCLE touch pad to access Cycle Review
mode, and review first phase of selected cycle.
CYCLE 6 HTW
PRE-WASH (E)T= 01:00
4. Continue to press REVIEW CYCLE to sequentially review each
phase of selected cycle.
CYCLE 6 SP=180.0F
FINAL RINSE (E)T= 01:30
NOTE: For Cycle Review mode, note the following:
1) Cycle Review mode also permits user to review programmed
solution temperature setpoint and actual detergent solution tem-
perature in detergent tank.
2) Extended treatment time is shown by an "E" before actual time.
5. Press REVIEW CYCLE touch pad until print message appears
on screen (if printer option is enabled).
PRINT CYCLE VALUES?
REVIEW = YES STOP = NO
6. To generate a printout of reviewed cycle phases and values,
press REVIEW CYCLE touch pad. Display screen returns to first
phase of selected cycle:
CYCLE 6 HTW
PREWASH T= 01:00
... and printer records:
CYCLE PROGRAM REVIEW
CYCLE - CYCLE 6
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
REVIEW TIME 5:18:25P
REVIEW DATE 4/24/05
UNIT NUMBER 3600000
SELECT
CYCLE
