4-26
122997-341 Operator Manual Washer Operation
5. When cooldown tank (option) is empty, display shows:
SUMP EMPTY
After a two-second delay, display returns to DRAIN Menu:
SUMP
ALK.TANK
ACID TANK COOLDOWN
__indicates flashing position.
4.11.2 Draining Alkaline Tank To drain Alkaline Tank manually, proceed as follows:
1. From Drain Menu, press SELECT CYCLE touch pad until ALK.
TANK is flashing. Display shows:
SUMP ALK.TANK
ACID TANK COOLDOWN
__indicates flashing position.
2. With ALK. TANK flashing, press CYCLE/START touch pad. Dis-
play shows:
ALK.TANK DRAINING
PRESS STOP TO ABORT
3. When sump is full, display shows:
SUMP FULL
4. After a three-second delay, jet valve(s) closes, sump drain
valve(s) opens and treatment pump(s) turns on. Display shows:
DRAINING SUMP...
PRESS STOP TO ABORT
5. Pump runs for DRAIN TIME. On completion, display shows:
FILLING SUMP...
PRESSSTOP TO ABORT
6. When sump is full, display shows:
SUMP FULL
7. After a three-second delay, jet valve(s) closes and sump drain
valve(s) opens, treatment pump(s) is turned on. Display shows:
DRAINING SUMP...
PRESS STOP TO ABORT
8. Pump runs for DRAIN TIME. On completion, display shows:
ALK. TANK
EMPTY
After a two-second delay, display returns to DRAIN menu:
SUMP ALK.TANK
ACID TANK COOLDOWN
__indicates flashing position.
SELECT
CYCLE
