122997-341 Operator Manual Component Identification
3.5.2 Sample Printout The following is an example of a typical cycle printout (see Figure 3-5):
• POWER UP
When POWER-OFF/STANDBY switch is set to POWER,
generated printout lists time and date control was turned on and
unit’s serial number.
• CYCLE START
When CYCLE/START touch pad is pressed twice to begin
selected cycle, generated printout lists name of cycle started,
time and date cycle was started, cycle number, and unit
number.
• IN-CYCLE PERFORMANCE
During a cycle, generated printout lists start and end time of
each phase, along with actual temperature of solution/water in
chamber sump.
• END-OF-CYCLE PERFORMANCE SUMMARY
At end of a cycle, generated printout lists time cycle was
completed, maximum wash and rinse temperatures reached
during cycle, and total cycle processing time.
• ALARM CONDITION
When an alarm condition occurs, generated printout lists type of
alarm and time it occurred (see Figure 3-6). Once operator
presses Alarm Reply touch pad, generated printout lists time
alarm was acknowledged.
Figure 3-5.Sample Printout
* CONTROL ON 8:32:31A
- - - - - - - - - - - - - - - - - - - - - - - -
CYCLE – CYCLE 1
- - - - - - - - - - - - - - - - - - - - - - - -
CYCLE START 8:37:33A
CYCLE DATE 4/24/05
CYCLE NUMBER 00000001
UNIT NUMBER 3600000000
PHASE TIME F
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
PRE-WASH 8:38:03A 141.5
8:39:03A 135.0
DET-WASH 8:41:33A 146.3
8:46:33A 144.2
RINSE 1 8:49:10A 183.5
8:50:40A 182.7
RINSE 2 8:53:00A 184.0
8:54:30A 182.5
F. RINSE 8:57:20A 184.3
8:58:50A 183.8
EXHAUST 8:59:50A 183.8
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
CYCLE COMPLETE 9:01:20A
MAX WASH TEMP= 146.3F
MAX RINSE TEMP= 184.3F
CYCKE TIME= 0:23:27
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
READY TO UNLOAD
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
DOOR OPENED 9:03:42A
Cycle Start In-Cycle Performance
End-of Cycle Performance
Summary
Figure 3-6. Sample Alarm Printout
PHASE TIME F
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
PREWASH 10:15:20A 163.5
10:17:02A 166.8
* ALARM 10:18:02A
SUMP
TOO LONG IN FILL
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
ALARM ACKNOWLEDGED
AT 10:18:15A
