4-27
Washer Operation Operator Manual 122997-341
4.11.3 Draining Acid Tank To drain Acid Tank manually, proceed as follows:
1. From Drain Menu, press SELECT CYCLE touch pad until ACID
TANK is flashing. Display shows:
SUMP ALK.TANK
ACID TANK
COOLDOWN
__indicates flashing position.
2. With ACID TANK flashing, press CYCLE/START touch pad. Dis-
play shows:
ACID TANK DRAINING
PRESS STOP TO ABORT
3. When sump is full, screen display shows:
SUMP FULL
4. After a three-second delay, jet valve(s) closes and sump drain
valve(s) opens, treatment pump(s) is turned on. Display shows:
DRAINING SUMP...
PRESS STOP TO ABORT
5. Pump runs for DRAIN TIME. On completion, display shows:
FILLING SUMP...
PRESS STOP TO ABORT
6. When sump is full, display shows:
SUMP FULL
7. After jet valve(s) closes and sump drain valve(s) opens, treat-
ment pump(s) is turned on. Display shows:
DRAINING SUMP...
PRESS STOP TO ABORT
8. Pump runs for DRAIN TIME. On completion, display shows:
ACID TANK
EMPTY
After a two-second delay, display returns to DRAIN menu:
SUMP ALK.TANK
ACID TANK
COOLDOWN
__indicates flashing position.
4.11.4 Draining Cooldown
Tank
To drain Cooldown tank manually, proceed as follows:
1. From DRAIN Menu, press SELECT CYCLE touch pad until
COOLDOWN is flashing. Display shows:
SUMP ALK.TANK
ACID TANK COOLDOWN
__indicates flashing position.
2. With COOLDOWN flashing, press CYCLE/START touch pad.
SELECT
CYCLE
