4-21
Washer Operation Operator Manual 122997-341
time. If a longer phase time is desired, programmed time setpoint
must either be manually extended during cycle or adjusted in
Change Values mode prior to starting cycle.
3. Press REVIEW CYCLE touch pad until print message appears
on screen (if printer option is enabled):
PRINT CYCLE VALUES?
REVIEW =YES STOP = NO
NOTE: To run cycle with extended phase times, cycle must be
started while in Cycle Review mode. To remain in Cycle Review
mode, operator must answer YES to print message by pressing
REVIEW CYCLE touch pad. If operator answers NO by pressing
STOP/RESET touch pad control exits Cycle Review mode,
display screen returns to cycle menu and any adjustments made
while in Cycle Review mode are erased.
4. Press REVIEW CYCLE touch pad to generate a printout of
reviewed cycle values and return display screen to first phase of
selected cycle. An "E" is printed next to each extended phase
time:
CYCLE PROGRAM REVIEW
CYCLE -CYCLE 6
REVIEW TIME 5:18:25
PREVIEW DATE 4/24/05
UNIT NUMBER 3600000
PHASE TIME F
PRE-WASH 01:00 HWT
DET-WASH 05:00 140.0
WATER DRAIN
TANK TEMP 140.0
RINSE 1 01:30 180.0
RINSE 2 03:00 180.0
F. RINSE 01:30 180.0G
EXHAUST 01:30 - - - - -
5. Press CYCLE/START touch pad twice to initiate cycle. Cycle
automatically progresses through each phase as temporarily
adjusted in Cycle Review mode.
NOTE: Cycle may be started at any point in Cycle Review mode.
6. On completion of cycle, alarm buzzer sounds and an operator
instruction is displayed.
7. When door(s) is opened, display screen returns to first cycle
menu, control exits Cycle Review mode and phase times return
to programmed time setpoints.
WARNING – BURN HAZARD: When cycle is complete,
partially open chamber door and allow chamber and
load to cool. Hot steam may escape through door
opening if door is fully opened after a cycle.
WARNING – SLIPPING HAZ-
ARD: To avoid slippery floor
conditions, keep floor dry.
Promptly wipe up any
spilled liquids or condensa-
tion. If spilled liquids are
detergents or other chemi-
cals, follow safety precau-
tions and handling
procedures set forth on
detergent or chemical label
and/or Material Safety Data
Sheet (MSDS).
WARNING – BURN HAZ-
ARD: Inner surfaces of
washer are very hot after
cycle completion. Operator
should wear appropriate
Personal Protective Equip-
ment (PPE) and avoid all
contact with inner walls
when entering chamber to
unload washer.
