5-9
Cycle Programming Operator Manual 122997-341
NOTE: This display is only shown if non-recirculated final rinse is
available.
12. Press VALUE (up or down) touch pad to toggle between YES
and NO answer. Selecting NO means that final rinse is non-recir-
culated. Selecting YES means that final rinse is recirculated.
13. Press CHANGE VALUES touch pad. Final Rinse Temperature
Guarantee option screen appears (only if final rinse is recircu-
lated):
GUAR.F.RINSE TEMP.
NO
__indicates flashing position.
14. Press VALUE (up or down) touch pad to toggle between YES
and NO answer. Selecting NO starts Final Rinse phase time
countdown at beginning of phase. Selecting YES guarantees
that Final Rinse phase time counts down only when water tem-
perature is equal to or greater than programmed set point.
NOTE: With Temperature Guarantee feature enabled, phase
time does not count down unless setpoint is reached. It is
important that set point be an attainable value. Guaranteed
temperature is shown by a G before setpoint (GSP instead of
SP).
15. Press CHANGE VALUES touch pad. The following message
screen appears:
REUSE F. RINSE WATER?
NO
__indicates flashing position.
NOTE: This question is not displayed if all three rinses are
bypassed. Water is reused, if final rinse is non-recirculated.
16. Press VALUE (up or down) touch pad to toggle between YES
and NO answer. Selecting YES retains rinse water in sump at
end of Final Rinse phase. Selecting NO pumps rinse water to
drain.
17. Press CHANGE VALUES touch pad. Exhaust Phase Values
screen appears:
CYCLE 10
EXHAUST T=M
M:SS
__indicates flashing position.
18. To enter Exhaust phase time, press CURSOR (left or right)
touch pad to select position and VALUE (up or down) touch
pad to select desired number (0-9). Phase time is input as min-
utes and seconds within a range of 0-49 minutes and 0-99 sec-
onds.
19. Press CHANGE VALUES touch pad. Print Cycle Values option
screen appears:
PRINT CYCLE VALUES?
NO
__indicates flashing position.
VALUE
VALUE
VALUE
VALUE
