Fork Carriage Width b3 (mm) 1380
Ground Clearance below Mast(laden) m1 (mm) 145
Ground Clearance at Centre of Wheelbase(laden) m2 (mm) 180
Working aisle width with pallet 1000 x 1200 cross-
ways****
Ast (mm) 4552
Working aisle width with pallet 800 x 1200 crossways**** Ast (mm) 4752
Turning Radius Wa (mm) 2790
Turning Point Minimum Distance from the Truck Center
Line
b13 (mm) 900
Performance data
Driving speed (with/without load) km/h 24/25
Lifting speed (with/without load) m/s 0.44/0.53
Lowering speed (with/without load) m/s 0.42/0.29
Drawbar Pull Tractive Effort (at 2km/h) with/without load KN 25/23
Gradeability (at 2km/h) laden/unladen % 20
Service Brake Mechanical/Hydraulic
Engine
Engine Type Deutz TCD2.9 L4
Engine Power in compliance with ISO 1585 kW 55.4
Rated Number of Revolutions rpm 2300
Cylinder Number/Displacement cm
3
4/2900
On-board voltage 12
Others
Drive Control Type
Hydraulic torque con-
vertor
Volume fuel tank L/Kg 90/75
Towing coupling, type DIN PIN
Technical datasheet
6
Data sheet RCD40
142 60128011601 EN - 03/2020
