Adjusting the fork arm distance
– Raise the knob (2) and rotate it by 90°.
– Adjust the fork arms (1) according to the di-
mensions of the load to be lifted.
– Ensure that an equal distance is maintained
from both fork arms to the centre line of the
fork carriage.
– Ensure that the fork arms are locked in one
of the grooves on the fork carriage using
the knob (2).
CAUTION
For greater load stability, the distance between the
two fork arms must be as large as possible while re-
maining consistent with the lifting points of the load,
so that the load centre of gravity is between the fork
arms.
CAUTION
For greater load stability, the position of the fork
arms must be as symmetrical as possible with re-
spect to the centre of the fork carriage.


Use and operation
4
Handling loads
78 60128011601 EN - 03/2020
