Data sheet RCD50
Characteristics
Manufacturer STILL
Model RCD50
Power type:Electric-Diesel-Petrol-LPG-Network Power
(Electric)
Diesel
Operation Type:Hand-stand on-Driver seated Seated
Load Capacity Q (kg) 5000
Load centre of gravity distance c (mm) 500
Axle centre to fork face x (mm) 567
Wheel Base y (mm) 2000
Weights
Service Weight Kg 7340
Axle loading, laden front/rear Kg 11000/1420
Axle loading, unladen front/rear Kg 3120/4200
Wheels, chassis frame
Tyres:SE-Super elastic PN-Pneumatic SE
Front Tyres Size 300-15-20PR
Rear Tyres Size 7.00-12-12PR
Front Track Width b10 [mm] Diesel
Rear Track Width b11 [mm] Seated
Dimension and overall sizes
Mast lift, forward/backward α/β 6°/12°
Mast Minimum Overall Height h1 mm] 2390
Free lift h2 [mm] 150
Lift height h3 mm] 3000
Mast Maximum Overall Height h4 mm] 4275
Overhead Guard Height h6 mm] 2260
Seat Height h7 mm] 1315
Drawbar Height h10 mm] 380
Overall Length I1 (mm) 4230
Lenght to Face of Forks I2 (mm) 3160
Overall Width b1 [mm] 1485
Fork Arm Dimensions s/e/l mm) 50/150/1070
Fork Carriage in Compliance with ISO 2328 Class/Form A,B III A
Fork Carriage Width b3 (mm) 1380
Ground Clearance below Mast(laden) m1 (mm) 145
Ground Clearance at Centre of Wheelbase(laden) m2 (mm) 180
Working aisle width with pallet 1000 x 1200 crossways**** Ast mm) 4597
Working aisle width with pallet 800x1200 crossways**** Ast mm) 4797
Turning Radius Wa (mm) 2830
Technical datasheet
6
Data sheet RCD50
14360128011601 EN - 03/2020
