Tilting the lift mast backward
– Push the control lever (2) back.
When transporting a load, tilt the lift mast
backwards for better stability.
Operating attachments
Attachments are optional pieces of equipment
installed on the forklift truck: (such as sideshift
forks, rotators, clips, etc.). Please do not ex-
ceed the working pressure of attachments dur-
ing operation, and ensure that operation is in
compliance with datasheets. One or two addi-
tional control levers can be installed to operate
attachments.
NOTE
Below is a description of attachment opera-
tions. The forklift truck can be configured with
different operating levers.
– Take note of the switching symbols with ar-
rows
Use and operation
4
Lifting system and attachments
7160128011601 EN - 03/2020
