Mast specification
NOTE
This data would be changed under different
working condition.
4T MAST SPECIFICATIONS
Mast
type
Max.
height
Rated capacity height free-lift height
mast an-
gle
load center
500mm
closed
height
height
with car-
riage
without
carriage
with car-
riage
4T
double
tyres
front/
back
VM
Stand-
ard
wide-
view
3000 4000 4000 2390 4275 150 150
6/123300 4000 4000 2540 4575 150 150
3500 4000 4000 2640 4775 150 150
4000 4000 4000 2940 5275 150 150
6/64500 4000 4000 3190 5775 150 150
5000 4000 4000 3440 6275 150 150
VFM
Full free
duplex
3000 4000 4000 2390 4275 1544 1165
6/123300 4000 4000 2540 4575 1694 1315
3500 4000 4000 2640 4775 1794 1415
4000 4000 4000 2890 5275 2044 1665 6/6
VFHM
Full free
triplex
3620 4000 4000 2145 4895 1299 920
6/6
3920 4000 4000 2245 5195 1399 1020
4350 4000 4000 2390 5625 1544 1165
4500 4000 4000 2441 5775 1595 1216
4700 4000 4000 2507 5975 1661 1282
4800 4000 4000 2540 6075 1694 1315
5000 4000 4000 2640 6275 1794 1415
5400 4000 4000 2765 6675 1919 1540
3/6
5500 4000 4000 2807 6775 1961 1582
6000 3480 4000 3005 7275 2159 1780
6200 3250 3750 3093 7475 2247 1868
