WARNING
Risk of accident from a falling load!
If the fork or the load remains suspended during low-
ering, the load may fall.
– When removing a load from storage, move the
truck far enough back so that the load and the fork
can be lowered freely.
– Drive up to the stack with the load lowered
in accordance with regulations.
– Set the lift mast to vertical.
– Lift the load to the stacking height.
– Drive the truck carefully into the stack. Use
the brake Inching pedal at the same time
– Lower the load until it rests securely on the
racking.
– Look behind!
– Move the truck back until the fork arms can
be lowered without touching the stack.
– Lower the fork to the ground clearance po-
sition.
– Tilt the lift mast backwards and drive away.
6210_800-015
6210_800-016
Use and operation
4
Handling loads
88 60128011601 EN - 03/2020
