6 | Installation STÖBER
28
11/2017 | ID 442793.00
6.6 Installing the drive controller without a rear section
module
This chapter describes the installation of the SC6 drive controller without a rear section module.
If you would like to connect SC6 drive controllers in the DC link, you must mount the required
rear section modules and then build the appropriate drive controllers over them.
DANGER!
Electrical voltage! Risk of fatal injury due to electric shock!
▪ Always switch off all power supply voltage before working on the devices!
▪ Note the discharge time of the DC link capacitors. You can only determine the absence of
voltage after this time period.
Information
Note that drive controllers in storage require reforming each year or before commissioning at
the latest.
Tool and material
You will need:
§ Fastening screws
§ Tool for tightening the fastening screws
Requirements and installation
Perform the following steps for each drive controller within the group and in the specified order.
ü In accordance with the drilling diagram, taking into consideration the various device
dimensions, you have made threaded holes for the threaded bolts on the mounting plate at
the installation position.
ü The mounting plate has been cleaned (free of oil, grease and swarf).
1. Fasten the top of the drive controller on the mounting plate.
2. Fasten the bottom of the drive controller on the mounting plate.
