STÖBER 7 | Connection
11/2017 | ID 442793.00
41
7.4.6 X4A: Encoder A
The encoder of axis A is connected to terminal X4A.
ATTENTION!
Risk of encoder destruction!
X4 may not be plugged in or unplugged when the device is switched on!
ATTENTION!
Risk of encoder destruction!
Only encoders with a suitable input voltage range (minimum 12V
DC
) may be connected to X4.
Unsuitable encoder types
The following STOBER encoder types may not be connected:
Encoder type Code according to type designation
ECI 1118 C0
EQI 1130 Q0
ECI 1319 CR
EQI 1329 QP
EQI 1331 QR
Tab. 29: Encoder types with unsuitable input voltage range
Information
Note that a master encoder must be connected to axis A.
