6.8 Mounting the drive controller on the rear section
module
DANGER!
Electrical voltage! Risk of fatal injury due to electric shock!
▪ Always switch off all power supply voltage before working on the devices!
▪ Note the discharge time of the DC link capacitors. You can only determine the absence of
voltage after this time period.
Information
Note that drive controllers in storage require reforming each year or before commissioning at
the latest.
Tool and material
You will need:
§ A suitable terminal set for each drive controller
§ A 8 mm hexagonal socket wrench to tighten the nuts
Requirements and installation
Perform the following steps for each drive controller within the group.
ü There is a circuit diagram of the system that describes the connection of the drive
controllers.
ü For each drive controller, the appropriate DL6B Quick DC-Link rear section modules for the
DC link connection have already been installed in the installation position.
1. Remove terminal X22 from the appropriate terminal set. Connect the brown cable D+ of the
bottom of the Quick DC-Link module to D+ of terminal X22, and the black cable D- of the
Quick DC-Link module to D- of terminal X22. Note that the terminal is only connected at a
later point in time.
2. Place the drive controller on the bottom threaded bolt of the Quick DC-Link module and
properly align it vertically with the bottom and top threaded bolt.
3. Fasten the drive controller with the nut and washer assemblies (M5) to both threaded bolts
of the Quick DC-Link module. The nut and washer assemblies are included with the Quick
DC-Link module.
4. Repeat the previous steps for each additional drive controller within the group.
