Stober SC6 Series Commissioning Instructions

STÖBER 7 | Connection
11/2017 | ID 442793.00
39
7.4.2 X2A: Motor holding brake A
The brake of axis A is connected to X2A. All device types of the SC6 drive controller can control
a 24V
DC
brake as standard.
Information
Note that motor holding brakes from other manufacturers may be connected only after
consultation with STOBER.
Controllable brakes
The technical data of the controllable brakes at X2A can be found in the manual for the SC6
drive controller; see the chapter Detailed information [
}70].
Term. Pin Designation Function
5 | 6
5 1BD1 Actuation of the brake
6 1BD2 Reference potential
Tab. 25: X2A connection description, A motor holding brake
Cable requirements
Motor connection Max. length of the power cable
Without output choke 50m, shielded
With output choke 100m, shielded
Tab. 26: Maximum cable length of the power cable [m]
