LEDs of interfaces
LEDs associated with Ethernet interfaces provide indications on the status of the connection.
following information on the connection:
SN160, SN160W, SN210, SN210W and SN310 models
Name Color Status Status
Front panel LED
ACT/LINK
Green On Link established between the Ethernet port and the connected appliance.
Off Ethernet port switched off or link not established with the connected
appliance.
Blinking The Ethernet port is sending or receiving data.
The blinking speed varies according to the volume of traffic.
SN160W and SN210W models
Name Color Status Status
Front panel Wi-Fi LED
ACT/LINK
Blue On
Wi-Fi interface on.
Off Wi-Fi interface off.
Blinking The Wi-Fi interface sends or receives data.
The blinking speed varies according to the volume of traffic.
SN510, SN710, SN910, SN2100 and SN3100 models
1 Gbps Ethernet ports
Name Color Status Status
Left LED
ACT/LINK
Green On Link established between the Ethernet port and the connected appliance.
Off Ethernet port switched off or link not established with the connected appliance.
Blinking The Ethernet port is sending or receiving data.
The blinking speed varies according to the volume of traffic.
Right LED
SPEED
Yellow On Media speed negotiated at 1Gbps.
Green On Media speed negotiated at 100 Mbps.
Off Media speed negotiated at 10 Mbps.
10 Gbps Ethernet ports
Name Color Status Status
Left LED
ACT/LINK
Green On Link established between the Ethernet port and the connected appliance.
Off Ethernet port switched off or link not established with the connected appliance.
Blinking The Ethernet port is sending or receiving data.
The blinking speed varies according to the volume of traffic.
Right LED
SPEED
Yellow On Media speed negotiated at 10Gbps.
Green On Media speed negotiated at 1Gbps.
Off Media speed negotiated at 100 Mbps.
SN6100 model
1 Gbps Ethernet ports (including IPMI)
Name Color Status Status
Left LED
ACT/LINK
Yellow On Link established between the Ethernet port and the connected appliance.
Off Ethernet port switched off or link not established with the connected appliance.
Blinking The Ethernet port is sending or receiving data.
The blinking speed varies according to the volume of traffic.
Right LED
SPEED
Yellow On Media speed negotiated at 1Gbps.
Green On Media speed negotiated at 100 Mbps.
Off Media speed negotiated at 10 Mbps.
