10 Gbps Ethernet ports
Name Color Status Status
Left LED
ACT/LINK
Green On Link established between the Ethernet port and the connected appliance.
Off Ethernet port switched off or link not established with the connected appliance.
Blinking The Ethernet port is sending or receiving data.
The blinking speed varies according to the volume of traffic.
Right LED
SPEED
Green On Media speed negotiated at 10Gbps.
Yellow On Media speed negotiated at 1Gbps
Off Media speed negotiated at 100 Mbps.
SNi40 model
Name Color Status Status
Upper LED
ACT/LINK
Yellow On Link established between the Ethernet port and the connected appliance.
Off Ethernet port switched off or link not established with the connected appliance.
Blinking The Ethernet port is sending or receiving data.
The blinking speed varies according to the volume of traffic.
Lower LED
SPEED
Yellow On Media speed negotiated at 1Gbps.
Green On Media speed negotiated at 100 Mbps.
Off Media speed negotiated at 10 Mbps.
Fiber Ethernet connectors
These Ethernet ports are available by default on the following models:
l SN910: ports 9 and 10 (via two sockets for SFP transceivers),
l SNi40: ports 6 and 7 (via two sockets for SFP transceivers),
l SN6100: ports MGMT1 and MGMT2 (via two sockets for SFP+ transceivers).
On SN710, SN910, SN2100, SN3100 and SN6100 models, fiber Ethernet connectors can be
added by inserting extension modules.
In both cases it is necessary to install a transceiver. SFP transceivers are used for 1Gbps
connections, SFP+ for 1Gbps/10Gbps connections or QSFP+ for 40Gbps connections (on
SN2100, SN3100 and SN6100).
IMPORTANT
Use only Stormshield Network-approved transceivers available in the catalogue.
LEDs
The LEDs indicate the following information:
1 Gbps connectors with SFP transceivers
l Default ports on SN910 and SNi40 models: a green LED will light up when the link is
established and blink depending on the volume of traffic.
l Extension modules for SN710, SN910, SN2100 and SN3100 models: a green LED will light up
when the link is established and blink depending on the volume of traffic.
SNS - PRODUCT PRESENTATION AND INSTALLATION 2019
NETWORK CONNECTORS
Page 37/66 sns-en-SNrange_installation_guide-2019 - 09/2019
