l Extension modules for SN6100:
Name Color Status Status
Left LED
ACT/LINK
Yellow On Link established between the Ethernet port and the connected appliance.
Off Ethernet port switched off or link not established with the connected appliance.
Blinking The Ethernet port is sending or receiving data.
The blinking speed varies according to the volume of traffic.
Right LED
SPEED
Yellow On Media speed negotiated at 1Gbps.
10 Gbps connectors with SFP+ transceivers
l Extension modules for SN710 and SN910:
Name Color/State Status
Left LED ACT/LINK Green/Blinking Link established between the Ethernet port and the connected appliance.
The blinking speed varies according to the volume of traffic.
Right LED SPEED Blue Media speed negotiated at 10Gbps.
Yellow Media speed negotiated at 1Gbps.
l Extension modules for SN2100 and SN3100:
Name Color/State Status
Left LED ACT/LINK Green/Blinking Link established between the Ethernet port and the connected appliance.
The blinking speed varies according to the volume of traffic.
Right LED SPEED Blue Media speed negotiated at 10Gbps.
Off Media speed negotiated at 1Gbps.
l Default ports and extension modules for SN6100:
Name Color Status Status
Left LED
ACT/LINK
Green On Link established between the Ethernet port and the connected appliance.
Off Ethernet port switched off or link not established with the connected appliance.
Blinking The Ethernet port is sending or receiving data.
The blinking speed varies according to the volume of traffic.
Right LED
SPEED
Green On Media speed negotiated at 10Gbps.
Off Media speed negotiated at 1Gbps.
40 Gbps connectors with QSFP+ transceivers
l Extension modules for SN2100 and SN3100:
Name Color Status Status
Left LED
ACT/LINK
Green/Blinking On Link established between the Ethernet port and the connected appliance.
Blinking The blinking speed varies according to the volume of traffic.
Right LED
SPEED
Green On Media speed negotiated at 40Gbps.
l Extension modules for SN6100:
Name Color Status Status
Left LED
ACT/LINK
Yellow On Link established between the Ethernet port and the connected appliance.
Off Ethernet port switched off or link not established with the connected appliance.
Blinking The Ethernet port is sending or receiving data.
The blinking speed varies according to the volume of traffic.
Right LED
SPEED
Yellow On Media speed negotiated at 40Gbps.
