SN2100 and SN3100 models
Front panel: connectors and LEDs
1 Online LED (green)
1 Status LED (green)
2 Power LED (yellow)
1 This is the button for resetting the appliance to its factory settings (defaultconfig).
2 Two USB 3.0 ports that can be used for secure configurations or upgrades. You may also plug
in a USB key, USB keyboard or approved USB modem.
3 The serial port allows accessing the product in console mode; it is possible to connect the
Firewall directly from a computer. The default baud rate on these models is 115 200 baud
(8N1).
4 SSD racks for log storage (1 SSD by default on SN2100 models, RAID available as an option, 2
in RAID 1 on SN3100 models).
5 The LEDs on SSD racks confirm whether the SSD has been accessed (blue LED on the right)
and installed (green LED on the left).
SN2100 model
This model is fitted with a multi-core CPU, making it possible to increase
processing power.
This product has an internal removable power supply and is equipped
with an SSD.
A second power supply module can be ordered separately for
redundant power supply. You can also order a second SSD for a RAID
installation.
1 OUT Interface
2 INInterface
The SN2100 model offers 2 1GbE ports and allows the addition of 3 extension modules with
RJ45 (Gigabit or 10 Gigabit) or fiber (Gigabit, 10 Gigabit or 40 Gigabit) connectors.
NOTE
For this model, network extension modules are sold separately and need to be ordered.
Specifications of Stormshield Network-approved extension modules and transceivers are set out
in sections Extension modules (SN710 and upwards) and Fiber Ethernet connectors.
