FFiigguurree 77 –– SSaaffeettyy bbaarr sseeccuurreedd iinn tthhee vveehhiiccllee ssaaffeettyy hhooookk
A
B
C
DE
FFiigguurree 88 –– VVeehhiiccllee ssaaffeettyy hhooookk ppllaacceemmeenntt
A Top view of vehicle
B Vehicle safety hook
C Squad bench
D Bumper
E Door frame
After installation, check that the cot legs lock into the load position without contacting the vehicle bumper.
6507-009-001 Rev AB.3 25 EN
