Stryker Power-PRO 2 - Securing the patient with the restraint straps

1
2
4
3
FFiigguurree 2211 –– RReessttrraaiinntt ssttrraapp aattttaacchhmmeenntt llooccaattiioonnss
AAttttaacchhiinngg tthhee sshhoouullddeerr rreessttrraaiinnttss
To attach the X-restraint shoulder restraints (Figure 22):
1. Wrap the restraint around the cot frame where the matching label is located (Figure 23).
2. Pull the restraint buckle through the loop, toward the head end of the cot.
3. Feed the buckle under the XPS system.
4. Pull the restraint through tight and toward the back of the backrest.
5. Feed the buckle through the opening in the backrest.
6. Connect the patient right shoulder buckle to the patient left waist buckle.
6507-009-001 Rev AB.3 39 EN
