Stryker Power-PRO 2 - Positioning operators and helpers

With both operators at the foot end With one operator at the foot end
and one operator on the side
With one operator (when unloading
an unoccupied cot)
a. Both operators: Grasp the cot
frame at the foot end.
b. Both operators: Pull the cot out
of the vehicle patient
compartment until the safety bar
connects with the vehicle safety
hook.
WWAARRNNIINNGG -- DDoo nnoott pprreessss tthhee
eexxtteenndd ((++)) bbuuttttoonn uunnttiill tthhee
ssaaffeettyy bbaarr ccoonnnneeccttss wwiitthh tthhee
vveehhiiccllee ssaaffeettyy hhooookk..
c. Operator 2: Make sure that the
safety bar connects with the
vehicle safety hook.
d. Operator 1: Depress the extend
(+) button to extend the cot
undercarriage.
e. Operator 2: Pull the safety bar
release lever forward to remove
the safety bar from the vehicle
safety hook.
a. Operator 1: Grasp the cot frame
at the foot end and pull the cot
out of the vehicle patient
compartment until the safety bar
connects with the vehicle safety
hook.
WWAARRNNIINNGG -- DDoo nnoott pprreessss tthhee
eexxtteenndd ((++)) bbuuttttoonn uunnttiill tthhee
ssaaffeettyy bbaarr ccoonnnneeccttss wwiitthh tthhee
vveehhiiccllee ssaaffeettyy hhooookk..
b. Operator 2: Grasp the cot outer
rail to stabilize the cot.
c. Operator 1: Depress the extend
(+) button to extend the cot
undercarriage.
d. Operator 2: Pull the safety bar
release lever forward to remove
the safety bar from the vehicle
safety hook.
a. Grasp the cot frame at the foot
end.
b. Pull the cot out of the vehicle
patient compartment until the
safety bar connects with the
vehicle safety hook.
WWAARRNNIINNGG -- DDoo nnoott pprreessss tthhee
eexxtteenndd ((++)) bbuuttttoonn uunnttiill tthhee
ssaaffeettyy bbaarr ccoonnnneeccttss wwiitthh tthhee
vveehhiiccllee ssaaffeettyy hhooookk..
c. Depress the extend (+) button to
extend the cot undercarriage.
d. Pull the safety bar release lever
forward to remove the safety bar
from the vehicle safety hook.
• Manual method - using the manual back-up release handle:
With both operators at the foot end
(recommended method)
With one operator at the foot end
and one operator on the side
With one operator (when unloading
an unoccupied cot)
a. Both operators: Grasp the cot
frame at the foot end.
b. Operator 1: Pull the manual
back-up release handle to
extend the cot undercarriage.
Pull the cot out of the vehicle
patient compartment until the
safety bar connects with the
vehicle safety hook. Release the
manual back-up release handle
when the base is fully extended.
c. Operator 2: Make sure that the
safety bar connects with the
vehicle safety hook. Pull the
safety bar release lever forward
to remove the safety bar from the
vehicle safety hook.
a. Operator 1: Grasp the cot frame
at the foot end. Pull the manual
back-up release handle to
extend the cot undercarriage.
Pull the cot out of the vehicle
patient compartment until the
safety bar connects with the
vehicle safety hook. Release the
manual back-up release handle
when the base is fully extended.
b. Operator 2: Make sure that the
safety bar connects with the
vehicle safety hook. Grasp the
cot outer rail to stabilize the cot.
Pull the safety bar release lever
forward to remove the safety bar
from the vehicle safety hook.
a. Grasp the cot frame at the foot
end.
b. Pull the manual back-up release
handle to extend the cot
undercarriage.
c. Pull the cot out of the vehicle
patient compartment until the
safety bar connects with the
vehicle safety hook.
d. Release the manual back-up
release handle when the base is
fully extended.
e. Pull the safety bar release lever
forward to remove the safety bar
from the vehicle safety hook.
PPoossiittiioonniinngg ooppeerraattoorrss aanndd hheellppeerrss
WWAARRNNIINNGG -- Always follow proper hand placement on hand grips. Keep all hands clear of the red safety bar pivots when
you load, unload, or change the cot height position.
EN 34 6507-009-001 Rev AB.3
