AAddddiinngg aa rreessttrraaiinntt ssttrraapp eexxtteennssiioonn
Add a restraint strap extension (6082-160-050) for extra length when you buckle the lap belt around larger patients.
FFiigguurree 2277 –– RReessttrraaiinntt ssttrraapp eexxtteennssiioonn
SSeeccuurriinngg tthhee cchhiilldd rreessttrraaiinntt wwiitthh tthhee XX--rreessttrraaiinntt ppaacckkaaggee
To attach the Britax Meridian SICT (series no. 7200/A/2010), Platinum Pro SICT (series no. 7200/A/2013i), and Millenia
SICT (series no. 7200/A/2013/i) Convertible Child Restraint to the cot with the X-restraint package (6500-001-430):
1. Lay the cot flat.
2. Open the waist restraint straps (6500-001-402 and 6500-001-403). Lay the straps to the side and out of the way.
3. Position the child restraint to face the foot end of the cot.
4. Place the child restraint in the reclined position.
5. Raise the cot Fowler up to align with the back of the child restraint.
6. Loop the upper anchorage strap with the anchor fitting and attachment clip from the child restraint around the cot Fowler
(Figure 28). Pull the adjustment strap to tighten and remove slack.
7. Pull the waist restraint under the siderail and through the bottom of the child restraint (Figure 29).
FFiigguurree 2288 –– AAnncchhoorraaggee ssttrraapp llooccaattiioonn FFiigguurree 2299 –– SSeeccuurree tthhee wwaaiisstt rreessttrraaiinntt
8. While firmly pushing down on the seat, pull the waist restraint with your other hand to tighten.
9. Attach one restraint strap (6500-001-404) to the foot end extension tube (Figure 30).
NNoottee -- The foot end extension tube must be in the mid or extended position (see
Extending or retracting the retractable
foot section
(page 36)).
EN 42 6507-009-001 Rev AB.3
