STULZ E
2
SERIES CONTROLLER FOR PERIMETER SYSTEMS OPERATION MANUAL
56
Display Description Variables Default
Assist Time
Enter the delay period for capacity assist unit(s) to begin
operating
if it is in the capacity assist mode.
0 to 999 300
Cooling Cut-In
Enter a temperature setpoint offset for cooling capacity
assist operation to begin.
-99.9 to 99.9 1.0
Cut-out
Enter a temperature setpoint offset for cooling capacity
assist operation to stop.
-99.9 to 99.9 0.0
Heating Cut-In
Enter a temperature setpoint offset for heating capacity
assist operation to begin.
-99.9 to 99.9 -1.0
Cut-out
Enter a temperature setpoint offset for heating capacity
assist operation to stop.
-99.9 to 99.9 0.0
Capacity Assist
Humid Cut in -4.0%
Cut out 0.0%
Dehum Cut in 4.0%
Cut out 0.0%
Service>Group>Capacity Assist (Screen 4)
The second Service>Group>Capacity Assist screen allows the adjustment
of local capacity assist humidifi cation and dehumidifi cation setpoints.
Display Description Variables Default
Humid Cut-in
Enter relative humidity setpoint offset for humidifying
capacity assist operation to begin
-99.9 to 99.9 -4.0
Cut-out
Enter relative humidity setpoint offset for humidifying
capacity assist operation to stop
-99.9 to 99.9 0.0
Dehum Cut-in
Enter relative humidity setpoint offset for dehumidifying
capacity assist operation to begin
-99.9 to 99.9 4.0
Cut-out
Enter relative humidity setpoint offset for dehumidifying
capacity assist operation to stop
-99.9 to 99.9 0.0
Group Sensors
Use lead sensor, avg,
min, or max of group
Temp/Hum: Local
Underfl oor: Local
Service>Group>Group Sensors (Screen 5)
The lead controller polls the controllers from all the A/C units in the work
group and calculates the averaged value of their Temperature sensors,
Humidity sensors and optional Underfloor Pressure sensors. It also
determines the minimum (lowest) temperature sensor value and the lowest
humidity sensor value in the A/C group and conversely, determines the
maximum (highest) temperature sensor value and maximum humidity sensor
value in the A/C group.
Display Description Variables Default
Temp/Hum
Control the work group using the sensors connected to
individual A/C units (Local) or control the work group using
network sensor values transmitted from the lead controller.
To control by network sensors, select from the network
sensor values to be Lead, Average, Min or Max values. The
selections made in this screen will affect all the controllers
in the work group no matter which controller the screen is
accessed from.
• Local
• Lead
• Average
• Minimum
• Maximum
Local
Underfl oor
• Local
• Average
Local
