Sulzer ABS PC 441 - Page 32

81307063I
EN
28
Calculatedoutowbasedonagiven
static head
OR
Note!
Whenapressuresensorismountedon
themainsthesetting”Sensoro󰀨setto
pumps”needstobesetforanaccurate
calculation!
Indication of current total
pump head
PUMP 1
PUMP 2
PUMP 3
PUMP 4
ACKN.ALARMTRENDSETTINGSTATUSMAIN
Show Status Pump Pit
Pump pit
System Overflow
Pump 1 -OFF-
Pump 2 Remote Blocked
Pump 3 -OFF-
Pump 4 Back-Pressure Block
Overflow -OFF-
Mixer Pumped Volume
Drain Pump Total Pump Head
Cleaner 8.17 m
Esc
 
Level based flow solution with a pressure sensor mounted on the mains for actual head
compensation
Use either a given static head or mount a pressure sensor on the outgoing mains to get the actual head. If a
pressuresensorismountedinthemainsdischargepipe,thecontrollerwillautomaticallycompensateforany
variances in the head. Having a pressure sensor mounted on the mains can also warn for potential problems
with a high mains pressure.
Suchaproblemcanoccurdueto:
Air entrapment in the mains
High load from other stations
Thiswillthennaturallyhaveanimpactonthecalculationsbutmoreimportantlyonthecostofpumping.
Lifting elevation = 18 m
Mid level 2.5 m from
lowest level
M = 18 m - 2.5 m = 15.5 m
Overflow at 5 m from
lowest level
H = 18 m - 5 m = 13 m
Lowest level 0 m
L = 18 m - 0 m = 18
m
Whenapressuresensorismountedontheoutgoingmains,theo󰀨setbetweenthepressuresensorandthe
intakeofthepumphastobeenteredtogetthecorrectactualhead.
PUMP 1
PUMP 2
PUMP 3
PUMP 4
ACKN.ALARMTRENDSETTINGSTATUSMAIN
Station Flow Outlet Pressure
Meas. Parameters Sensor offset to pumps
Pit Area 4.00 m
Outlet Presssure
Esc
 
Distancebetween
pressure sensor and
suction point of pump
Actual current
pump head
Current mains
pressure
