S CLASS™ 2 cutter User’s Manual
Specifications 6-5
6.2.4 Interface
Communication
USB and Ethernet 10/100 base connection
USB I/O Port connector USB series “B” receptacle (female plug)
Mating connector USB series “B” plug (male plug)
Version 1.1
Ethernet
I/O Port connector RJ45 female connector
USB
Flash
Drives
USB A receptacle
FAT 32, max 8GB and max 100 files.
Only cut files (DMPL and HPGL files)
or firmware files ( files with extension summa1)
FIG 6-4
6-4 S CLASS 2 INTERFACE SPECIFICATIONS
6.2.5 Firmware
Language
(*)
DM/PL, HP-GL (758x emulation), HP-GL/2
Supported character sets Standard ASCII
Supported fonts Sans serif (single stroke & medium)
ROM-based plots Confidence plot, DIN plot
(*)
The cutter detects the emulation language automatically at the start of the sent cut data.
FIG 6-5
6-5 S CLASS 2 FIRMWARE
