S CLASS™ 2 cutter User’s Manual
Detailed Operation 4-12
Menu Units:
The setting of these options determines whether the speed and size values are displayed in
the metric measure system or ENG/US measure system.
Press the Menu units button, then set it to the desired measure system.
Press to confirm or to cancel. The panel units are chosen when the cutter is
switched on for the first time.
LCD contrast:
The LCD contrast submenu is used to adjust the contrast (or intensity) of the touch screen.
The firmware automatically rejects values that would make the touch screen too dark to be
able to use it.
Press the LCD contrast button and set it to the desired value.
Press to confirm or to cancel.
4.3.1.10 OPOS
The OPOS settings are explained in detail in section 3, except for the Alignment mode and
Monitor.
Alignment:
There are three additional alignment methods available on all S CLASS 2 cutters:
X-Alignment, XY-Alignment and XY-Adjustment. These alignment methods can be used if
the combination of mark color – media color cannot be read by the OPOS sensor.
These alignment methods require that the user registers marks manually, using the cutter’s
keypad. Most cutting software can put these marks around the printed graphic
automatically.
X-Alignment compensates for errors in media alignment by rotating the graphic’s contour.
This alignment method requires that the user specifies the origin and one point along the
X-Axis. X-Alignment is the easiest alignment method.
XY-Alignment compensates for errors in graphic rotation and skew. Skew errors occur when
the graphic’s X- and Y-axes are not perpendicular. This alignment method requires that the
origin and one point along both the X- and Y-axes are specified.
XY-Adjustment compensates for errors in graphic rotation, skew, and scale. Scale errors
occur when the graphic’s printed size is different from the graphic’s original size, as created
in the imaging software. X-Distance and Y-Distance parameters are required. These
parameters define the distance between the origin and the X-axis point, and between the
origin and Y-axis point. XY-Adjustment is the most accurate manual alignment method.
Monitor:
This option shows the read-out of the reflection of the OPOS sensor. The values can be
used to report a problem to a certified service technician.
