Basic Operation 2-1
2 Basic Operation
2.1 Touch Screen
The 320x240-dot touch screen provides a unique interface system that provides detailed
cutter status information and offers a more flexible and powerful control of the cutter’s
configuration.
All screen and optional panel controls on the touch screen are easily formatted to allow
quick access to the most common cutter settings.
Next to the status messages and/or menu options, displayed on the touch screen, button
symbols can be pressed to change menu items or to change the value for a given
submenu/parameter.
FIG 2-1
2-1 TOUCH SCREEN
There is also screen saving feature. After a certain amount of time the screen goes blank
and this logo appears on the screen. Touching the screen once disables the screen saver.
FIG 2-2
2-2 SCREEN SAVER
Each keystroke can initiate an internal test or movement of the
head or media. Keep fingers and other body parts away from the cutting area.
