Mode Select (6)
108 SL500: Interface Reference Manual • July 2008 Revision: F • 96122
Low Voltage Differential SCSI Logical Unit Page
The following table shows the format of the SCSI (LVD) Logical Unit Page.
TABLE 6-22 SCSI (LVD) Logical Unit Page
Byte
Bit
76543210
0 PS (0) SPF (0) Page Code (18h)
1 Page Length (06h)
2 Reserved Protocol Identifier (1h)
3
to
7
(MSB)
Reserved
(LSB)
SCSI (LVD) Logical Unit Page Definitions:
PS The Parameters Saveable bit is set to 0.
SPF The library returns a value of 0 for the SubPage Format bit, indicating page_0
format is being used.
Protocol Identifier The field is set to 1h indicating the Parallel SCSI protocol.
