Mode Sense (10)
96122 • Revision: F Chapter 6 SCSI Commands 165
388
to
392
Numbers for column 8, module 6
393 Reserved (0)
394
to
398
Numbers for column 9, module 6
399 Reserved (0)
400
to
404
Numbers for column 10, module 6
405 Reserved (0)
406
to
410
Numbers for column 11, module 6
411 Reserved (0)
TABLE 6-56 Module Type Definitions
Module Type Field Definitions
0 Module not installed
1 The last installed 4U module with drives
2 The last installed 4U module with storage cells in the back
3 A 4U module with drives
4 A 4U module with storage cells followed by a module with drives
5 A 4U module with storage cells followed by a module with storage cells
6 The last installed 4U card unit
7 A 4U card unit
8 The last installed 8U module with drives
9 The last installed 8U module with storage cells in the back, below a module with drives in the back
10 The last installed 8U module with storage cells in the back, below a module with storage cells in the back
11 An 8U module with drives
12 An 8U module with storage cells in the back between modules with drives in the back
13 An 8U module with storage cells in the back below a module containing storage cells, and above a module with
drives in the back
14 An 8U module with storage cells in the back below a module containing drives, and above a module with
storage cells in the back
