Mode Sense (10)
96122 • Revision: F Chapter 6 SCSI Commands 147
Fibre Channel Port Control Page
The following table shows the format of the Fibre Channel Port Control page.
TABLE 6-49 Fibre Channel Port Control Page
Byte
Bit
76543210
0 PS (0) Rsvd Page Code (19h)
1 Page Length (06h)
2 Reserved Protocol Identifier (0h)
3 DTFD PLPB DDIS DLM DSA ALWI DTIPE DTOLI
4 Reserved
5 Reserved
6 Reserved RR_TOV units
7 Resource Recovery Time Out Value (RR_TOV)
Fibre Channel Port Specific Control Page Definitions:
PS The Parameters Saveable bit is set to 0.
Protocol Indentifier This field is set to 0h indicating the Fibre Channel protocol.
DTFD Disable Target Fabric Discovery
■ 0 = Public Loop behavior supported
■ 1 = Private Loop only supported
PLPB Prevent Loop Port Bypass will always be 0
DDIS Disable Discovery will always be 0
DLM Disable Loop Master will always be 0
DSA Disable Soft Address will always be 0
ALWI Allow Login Without Loop Initialization
will always be 0
DTIPE Disable Target Initiated Port Enable will always be 0
DTOLI Disable Target Originated Loop Initialization
will always be 0
RR_TOV units Resource Recovery Time Out Value Units
will always be 100b = 10 second units
RR_TOV Resource Recovery Time Out Value
will always be 1Eh = 300 seconds
