Read Element Status
192 SL500: Interface Reference Manual • July 2008 Revision: F • 96122
Import/Export Element Descriptor Definitions
Import/Export elements are the CAP and/or Pass-thru cells of the library. The
Import/Export Element Descriptor describes a CAP cell.
TABLE 6-75 Import/Export Element Descriptor
Byte
Bit
76543210
0
to
1
(MSB)
Element Address
(LSB)
2 OIR CMC InEnab
(1)
ExEnab
(1)
Access Except ImpExp Full
3 Reserved (00h)
4 Additional Sense Code
5 Additional Sense Code Qualifier
6 Reserved (00h)
7 Reserved (00h)
8 Reserved (00h)
9SValidInvert
(0)
Reserved (00h) ED Medium Type
10
to
11
(MSB)
Source Storage Element Address
(LSB)
12
to
47
Primary Volume Tag Information
(Field omitted if PVolTag=0)
48 Reserved (0h) Code Set (0)
49 Reserved (0h) Identifier Type (0)
50 Reserved (00h)
51 Identifier Length (0)
52 Media Domain
(Field moved up if Primary Volume Tag Information omitted.)
53 Media Type
(Field moved up if Primary Volume Tag Information omitted.)
54
to
55
Reserved (00h, 00h)
(Field moved up if Primary Volume Tag Information omitted.)
