Cables and Connectors
96122 • Revision: F Chapter 4 Fibre Channel Physical Interface 39
Cables and Connectors
Because the link to a port can be driven either optically or electrically, the term
“fibre” in Fibre Channel refers to either a fiber optic or a copper cable.
■ Optical transmission occurs over both single and multi–mode fibers using both
laser and light emitting diodes (LEDs) for both short (770–850 nm) and long
(1300–1360 nm) wavelengths.
■ Electrical transmissions occur over video coax, miniature coax, twin coax (Twin
Ax), or twisted pair.
TABLE 4-1 lists the cable and connector specifications that the libraries support.
TABLE 4-1 StorageTek Library Cables and Connectors
Distance
FC-0 Code
(see note) Cable Type ConnectorMeters Feet
2-150 6.5-490 200-M6-SN-1 62.5 µm
Multimode
780 nm
Shortwave laser
w/o OFC
Keyed Duplex LC
2–300 6.5–985 100-M6-SN-I 62.5 µm
Multimode
Shortwave laser
w/o OFC
Keyed Duplex SC
2–500 6.5–1640 100-M5-SN-I 50 µm
Multimode
Shortwave laser
w/o OFC
Keyed Duplex SC
Notes:
See FIGURE 4-4 for a description of the FC-0 code information.
See
TABLE 4-2 for specific part numbers.
FIGURE 4-4 FC-0 Level Communication About Media (Cables)
100-M5-SN-I
Distance
L = long
I = intermediate
S = short
Speed
400 = 400 MBps “Quadruple-speed”
200 = 200 MBps “Double-speed”
100 100 MBps “Full-speed”
50 50 MBps “Half-speed”
25 25 MBps “Quarter-speed”
12 12 MBps “Eighth-speed”
=
=
=
=
Media
SM = single-mode fiber
M5 = multi-mode (50 µm)
M6 = multi-mode (62.5 µm)
TV = video cable
MI = miniature coax cable
TP = twisted
air
Transmitter
LL = long wave laser (1,300 nm)
SL = short wave laser with OFC (770-850 nm)
SN =
LE = long wave LED
EL = electrical
short wave laser without OFC (770-850 nm)
