96122 • Revision: F 235
APPENDIX
A
Cell Maps
This appendix describes the SL500 Library System walls, cartridges cells (slots),
and location scheme.
Library Walls
There are three types of walls in the library:
■ Left side wall, which consists of 4-cartridge cell arrays
■ Right side wall, which consists of 3-cartridge cell arrays and 1 CAP array
■ Rear wall, which consists of either 3-cartridge expansion cell arrays or 1 drive
array
FIGURE A-1 on page 237 and FIGURE A-2 on page 238 show valid slot and drive
locations.
Cartridges placed in cells lie flat, hub down and parallel to the floor. To prevent
slippage, cartridges are held within their cell by internal retainer clips.
Cartridge Cell Locations – Data Cartridges
Cartridge locations in previous libraries were listed by Panel, Row, and Column.
Cartridge cell designations within a SL500 library require four parameters LSM,
Module, Column, Row:
1. LSM (Library number) — Within a library or library complex
2. Module — Modules are numbered 1,2,3... etc., from the top of the library to the
bottom
3. Column number – Columns are represented by numbers 1 through 11. Column
1 is the front most column on the left side of the library, and columns increase to
column 4 along the left wall. Column 5 is on the right side of the library closest
